Insulated 20ft Prefab Outdoor Gym Pod - Fire-Proof Steel Frame

Good to Know

• Price: Applies to standard 4-bedroom villa model configurations only.

• Photos: Visuals are for inspiration; actual units are built to standard specs unless upgraded.

• Shipping: Shipping costs are calculated based on destination and are not included in the base price.

• Customization: Contact our team for floor plan adjustments and detailed freight quotes.

Product Specifications

Dimensions

• Exterior Size: 96.46 x 228.35 x 112.99 in

Frame Structure

• Main Frame: 13 gauge (0.09 in) Q235 steel (top, bottom, and columns)

• Finish: Welded, rust-removed, galvanized, and electrostatic powder sprayed

• Corner Castings: 0.14 in Q235 galvanized standard lift pieces

Roofing System

• Outer Layer: 0.016 in color steel sheet

• Insulation: 3 in fiberglass wool with silver foil (Grade A fire-proof)

• Ceiling: 0.016 in integrated V-831 type color steel sheet

Wall System

• Panels: 3 in Rock Wool Board (0.013 in steel skin)

• Density: 5 lb-cu ft (Grade A fire-proof and non-flammable)

Floor System

• Subfloor: 0.71 in thick fiber cement board

• Finish: 0.06 in thick durable plastic flooring

Windows and Doors

• Windows: Two sets of 36.61 x 44.49 in PVC sliding windows with security bars and flyscreens

• Door: One set of 33.07 x 80.12 in dark grey security door with integrated lock

Electrical System

• Lighting: Two 15W LED fixtures

• Power Outlets: One AC socket and four general-purpose sockets

• Wiring: High-capacity main (10 AWG equivalent), AC (12 AWG equivalent), and lighting (14 AWG equivalent) cables

• Distribution: IP44 rated box with CEE industrial plug (220V-250V / 2P32A)

Accessories

• Drainage: Four 2 in PVC rainspouts

• Hardware: Full set of self-tapping screws, industrial glue, edge covers, and galvanized bolts
